Ubiquiti PowerBeam5 AC Gen2 High-Performance airMAX ac Bridge (PBE-5AC-Gen2-US)
Call For Best Price
Product details
| Dimensions | 420 x 420 x 230mm (16.54 x 16.54 x 9.06″) |
| Weight | 2.22 kg (4.89 lb) |
| Enclosure materials | UV-stabilized plastic, powder-coated SPCC |
| Wind loading | 380 N at 200 km/h (85.4 lbf at 125 mph) |
| Wind survivability | 200 km/h (125 mph) |
| Mounting | Pole mount kit (Included) |
- Description
- Size Guide
- Reviews (0)
Description
Ubiquiti PowerBeam ac Gen2 High-Performance airMAX ac Bridge (PBE-5AC-Gen2-US)
Ubiquiti Powerbeam 5AC GEN 2 High-performance 5 GHz Point-to-Point (PtP) bridge with integrated dish reflector. Provides up to 450+ Mbps data throughput.
Powerful dish reflector design with proprietary airMAX ac chipset and dedicated management WiFi for easy UISP® mobile app support and fast setup. Excellent beam directivity provides the best performance for PtP or PtMP links located in high-noise environments.
Features:
-
- Improved radio design
- Improved mounting
- Improved surge protection
- Management WiFi Radio/UISP mobile app
- AirOS 8
- Ubiquiti Powerbeam 5AC GEN 2Â Dealer in Delhi Nehru Place
Product Description
Where high-performance, durability, and reliability meet, you’ll find the PowerBeam AC GEN2 5GHz airMAX ac Bridge. This advanced piece of technology is the latest generation of airMAX CPE (Customer Premises Equipment) from Ubiquiti Networks, designed with a dedicated Wi-Fi management system for seamless connectivity.
| Mechanical | |
|---|---|
| Dimensions | 420 x 420 x 230mm (16.54 x 16.54 x 9.06″) |
| Weight | 2.22 kg (4.89 lb) |
| Enclosure materials | UV-stabilized plastic, powder-coated SPCC |
| Wind loading | 380 N at 200 km/h (85.4 lbf at 125 mph) |
| Wind survivability | 200 km/h (125 mph) |
| Mounting | Pole mount kit (Included) |
| Hardware | |
| Networking interface | (1) GbE RJ45 port |
| Power method | Passive PoE (Pairs 4, 5+; 7, 8 Return) |
| Max. power consumption | 8.5W |
| Power supply | 24V, 0.5A Gigabit PoE adapter (Included) |
| Supported voltage range | 20—26V DC |
| ESD/EMP protection | Air/contact: ± 24 kV |
| LEDs | (1) Power, (1) LAN, (4) WLAN |
| RoHS compliance | Yes |
| Salt fog test | IEC 68-2-11 (ASTM B117) Equivalent: MIL-STD-810 G method 509.5 |
| Vibration test | IEC 68-2-6 |
| Temperature shock test | IEC 68-2-14 |
| UV test | IEC 68-2-5 at 40° C (104° F) Equivalent: ETS 300 019-1-4 |
| Wind-driven rain test | ETS 300 019-1-4 Equivalent: MIL-STD-810 G method 506.5 |
| Operating temperature | -40 to 70 C (-40 to 158 F) |
| Operating humidity | 5 to 95% noncondensing |
| Certifications | CE, FCC, IC |
| System | |
| Gain | 25 dBi |
| Channel sizes | PtP Mode: 10/20/30/40/50/60/80 MHz PtMP Mode: 10/20/30/40 MHz |
| Operating Frequency (MHz) | |
| Worldwide | 5150-5875 MHz |
| USA U-NII-1 U-NII-2A U-NII-2C U-NII-3 |
5150-5250 MHz 5250-5350 MHz 5240-5725 MHz 5725-5850 MHz |
| Management Radio (MHz) | |
| Worldwide | 2412 – 2472 MHz |
| US/CA | 2412 – 2462 MHz |
