Description

DIGISOL 8 Port PoE Fast Ethernet Unmanaged Switch with 2 Uplink Ports DG-FS1010PF-G

DIGISOLDG-FS1010PF-G Switch offers 8×10/100Mbps Ethernet ports with Power over Ethernet support with 2 *1000Mpbs Uplink ports. These PoE ports are IEEE 802.3afand IEEE802.3at compliant and can supply up to a Max. of30 watt per port and a total PoE powerof150Watt. The existing Ethernet cables can be used to power up PoE compliant network devices. This eliminates the need of an external power source and power cabling for such devices. The switch provides flexibility to users for connecting a PoE or non PoE device.

The DIGISOL DG‑FS1010PF‑G is a robust Fast Ethernet unmanaged PoE switch featuring 8×10/100 Mbps PoE ports plus 2×Gigabit uplink ports, designed to streamline deployment across SOHO, surveillance, enterprise, and mixed-device networks. Moreover, this device delivers power and connectivity with zero configuration required—making it a plug‑and‑play solution right out of the box.

First and foremost, the 8 PoE ports comply with IEEE 802.3af (15.4 W) and IEEE 802.3at (30 W) standards, providing a generous up to 30 W per port, with a total PoE budget of 150 W. Consequently, you can power a mix of IP cameras, VoIP phones, access points, or other PoE-equipped devices using existing Ethernet cabling—eliminating the need for separate power adapters or wiring complexity.

Additionally, the switch supports auto MDI/MDIX on all ports, removing the necessity for crossover cables or special uplink configurations. In addition, the 2 Gigabit uplink ports ensure seamless integration with backbone switches or routers, enhancing performance and scalability.

Importantly, the DG‑FS1010PF‑G uses store-and-forward packet-switching, which inspects each packet for integrity before forwarding. As a result, the network maintains reliable, error-free communication even under peak load.

Key Highlights:

• 8 × PoE-enabled 10/100 Mbps ports (IEEE 802.3af/at compliant)

• 2 × 1 Gbps uplink ports for backbone connectivity

• Total PoE budget: 150 W (up to 30 W per port)

• Auto MDI/MDIX support for all ports

• Store-and-forward packet switching

• 5.6 Gbps switching capacity (full-duplex)

• Forwarding rate: ~4.166 Mpps per port

• MAC Address Table: 2K entries; 1 Mbit buffer memory

• Distance support: 250 m at 10 Mbps; 100 m at 100 Mbps

• 6 kV lightning protection and surge defense

• Silent, fanless operation with built-in AC power supply

• Wall‑mountable and compact design
