Description

DIGISOL 24 Port PoE Gigabit Ethernet Unmanaged Switch-DG-GS1028PF-B

DIGISOL DG-GS1028PF-B Switch offers 24×10/100/1000Mbps Ethernet ports with Power over Ethernet support with 2*1000Mbps Base-T and 2*1000Mbps SFP uplink ports. These PoE ports are IEEE 802.3af and IEEE 802.3at compliant and can supply up to a Max. of 30 watt per port and a total PoE power of 300 watts. The existing Ethernet cables can be used to power PoE compliant network devices connected to the PoE switch. This eliminates the need for an external power source and power cabling for such devices. The switch provides flexibility to users for connecting a PoE or non PoE device. The PoE devices connected to the switch can be easily identified by the separate PoE LED status indicators for each port

To begin with, all 24 PoE-enabled RJ45 ports fully comply with IEEE 802.3af and IEEE 802.3at standards. Consequently, the switch can deliver up to 30 W per port, with an impressive total PoE budget of 300 W—perfect for powering IP cameras, access points, or VoIP phones using existing Ethernet cabling.

Moreover, each port supports auto MDI/MDIX, eliminating the need for crossover cables and simplifying installation. In addition, the two dedicated Gigabit uplink ports and SFP expansion slots support fiber connectivity—providing high-speed backbone integration and scalability.

With a robust switching capacity of 56 Gbps full-duplex and a forwarding rate of approximately 41.66 Mpps, the switch maintains smooth and reliable performance even under heavy traffic.

Key Features at a Glance:

• 24 × Gigabit PoE ports (IEEE 802.3af/at compliant)

• 2 × 1000 Mbps RJ45 uplinks + 2 × 1 Gbps SFP uplinks

• 300 W PoE power budget (max 30 W/port)

• Auto MDI/MDIX support

• 56 Gbps switching capacity; ~41.66 Mpps forwarding rate

• Store-and-forward architecture

• AI self-healing mode (watchdog)

• 4 kV surge protection

• Silent fanless operation, built-in power supply

• Rack-mountable form factor

In summary, the DIGISOL DG‑GS1028PF‑B delivers high-density PoE capability, enterprise-grade performance, and resilient features—making it a reliable, plug‑and‑play choice for wired networks requiring durable PoE support.
