Name: TP-Link CPE510 5GHz N300 Long Range Outdoor Point to Point Wireless Bridge
Brand: TP-Link
SKU: PT0003-1
Rating: 5.00 (1 reviews)

Hot

TP-Link CPE510 5GHz N300 Long Range Outdoor

TP-Link CPE510 5GHz N300 Long Range Outdoor Point to Point Wireless Bridge

5.00 out of 5

1 customer review|Add a review

Call For Best Price

Product details

Processor	Qualcomm Atheros Enterprise 560MHz CPU, MIPS 74Kc
Memory	64MB DDR2 RAM, 8MB Flash
Interface	1 10/100Mbps Shielded Ethernet Port (Passive PoE in)
Power Supply	Passive Power over Ethernet via LAN0 (+4,5pins; -7,8pins) Voltage range: 16-27VDC
Power Consumption	10.5 Watts Max
Dimensions ( W x D x H )	8.8 x 3.1 x 2.4 in

SKU: PT0003-1 Categories: Access Point, Outdoor Access Point, TP-Link Access Point Brand: TP-Link

Add to wishlist

Compare

Description
Size Guide
Additional information
Reviews (1)
Custom Tab

Description

TP-Link 5GHz N300 Long Range Outdoor CPE for PtP and PtMP Transmission | Point to Point Wireless Bridge | 13dBi, 15km+ | Passive PoE Powered w/Free PoE Injector | Pharos Control (CPE510) White

About this item

TP-Link CPE510 5GHz N300 Long Range Outdoor Wireless Bridge
Built-in 13dBi 2×2 Dual-Polarized Directional MIMO Antenna: Featuring a built-in 13dBi 2×2 dual-polarized directional MIMO antenna, this device is designed for focused and efficient wireless transmission. Consequently, it can achieve better signal strength and coverage in a specific direction.

Adjustable Transmission Power: With adjustable transmission power ranging from 0 to 23dBm/200mw, users have the flexibility to fine-tune the signal output. Therefore, you can optimize the device for various deployment scenarios and regulatory requirements.

System-Level Optimizations for Long-Range Transmission: This device incorporates system-level optimizations specifically designed for long-range wireless transmission extending beyond 15km. As a result, it is well-suited for establishing reliable connections over significant distances.
TP-LINK Pharos MAXtream TDMA Technology: Integrating TP-LINK’s Pharos MAXtream TDMA (Time-Division-Multiple-Access) technology significantly improves product performance. Specifically, it enhances throughput, capacity, and latency performance, making it ideal for Point-to-MultiPoint (PTMP) applications.

Centralized Management System – Pharos Control: Equipped with the Centralized Management System – Pharos Control, this device offers simplified network administration. Moreover, this centralized platform allows for easy configuration, monitoring, and management of multiple devices.
Multiple Operation Modes: Supporting various operation modes including AP, Client, Bridge, Repeater, AP Router, and AP Client Router (WISP), this device provides versatile deployment options. Thus, it can adapt to a wide range of network topologies and requirements.

Processor	Qualcomm Atheros Enterprise 560MHz CPU, MIPS 74Kc
Memory	64MB DDR2 RAM, 8MB Flash
Interface	1 10/100Mbps Shielded Ethernet Port (Passive PoE in)
Power Supply	Passive Power over Ethernet via LAN0 (+4,5pins; -7,8pins) Voltage range: 16-27VDC
Power Consumption	10.5 Watts Max
Dimensions ( W x D x H )	8.8 x 3.1 x 2.4 in
Antenna Type	Built-in 13dBi 2 x 2 Dual-polarized Directional Antenna Beam Width: 45° (H-Plane) / 30° (E-Plane)
Protection	15KV ESD Protection 6KV Lightning Protection
Enclosure	Outdoor ASA stabilized plastic material IPX5 waterproof Certification

WIRELESS FEATURES
Wireless Standards	IEEE 802.11a/n (with Pharos MAXtream disabled)
Proprietary Protocol	TDMA Mode (with Pharos MAXtream enabled)
Wireless Speeds	Up to 300Mbps (40MHz,Dynamic) Up to 144.4Mbps (20MHz,Dynamic)
Frequency	5.15~5.85GHz
Transmission Power	23dBm/200mw (Adjustable power by 1dBm)
